ico dim

SIZE (MM)

560X760
h 1330

ico weight

CAPACITY

24 kg

ico power

POWER

2,2 kw

Quantity, quality, and practicality.

With a tank having a 24kg. capacity, the TEMPERING 20 is the perfect choice for those who want quality, speed and simplicity. The foot-pedal operated dispenser, which is featured on other POMATI tempering machines, allow operators maximum control and efficiency..

download the brochure REQUEST AN ESTIMATE

Customized courses for chocolate processing
FOR INFO CONTACT US NOW

logo pomati open

Watch the video

It features many accessories.

From the plexiglass cover to the dispensing plate — select the T 20 TEMPERING MACHINE accessories that best suit your needs.

ttunnel

It features many accessories.

From the plexiglass cover to the dispensing plate — select the T 20 TEMPERING MACHINE accessories that best suit your needs.

Specifications

Technical features Structure Entirely made in AISI 304 stainless steel
  Capacity 24 kg. tank
  Dispenser Programmable foot- pedal operated dispenser
  Tank Heated and thermosealed chocolate tank
  Heating Double heating circuit for tank, auger, and vibrating table
  Auger Removable auger for easy cleaning and change chocolate products, reverse direction for chocolate unloading
  Thermostats Thermostats to control temperature with great precision
  Refrigeration unit Refrigerating unit – Refrigerating unit with forced-air cooling system
  Power 400 Volt – Hz 50 – KW 2,2 Tri-phase 5 poles (customized voltages available)
  Dimensions 560 (740 with table) x 760 x h 1330 mm
Available accessories Enrobing belt (see details)
  Tilting Enrobing Belt (see details)
  Rotating table for truffles (see details)
  Exit conveyor belt (see details)
  Plexiglass cover (see details)
  Heating lamp (see details)
  Decorator (see details)
  Dispensing plate (see details)
  Pneumatic valve (see details)

Specifications

Technical features

  • Structure: Entirely made in AISI 304 stainless steel
  • Capacity: 24 kg. tank
  • Dispenser: Programmable foot- pedal operated dispenser
  • Tank: Heated and thermosealed chocolate tank
  • Heating: Double heating circuit for tank, auger, and vibrating table
  • Auger: Removable auger for easy cleaning and change chocolate products, reverse direction for chocolate unloading
  • Thermostats: Thermostats to control temperature with great precision
  • Refrigeration unit: Refrigerating unit – Refrigerating unit with forced-air cooling system
  • Power: 400 Volt – Hz 50 – KW 2,2 Tri-phase 5 poles (customized voltages available)
  • Dimensions: 560 (740 with table) x 760 x h 1330 mm

Available accessories
